| AEF9D | For fieldbus (for single or dual redundant modules) | 4 ports x 4 | M4 screws | ALF111 | AKB336 |
| Model | Description | Points | Terminals | Modules Connected |
Connection Cable |
Weight | Specifications |
|---|---|---|---|---|---|---|---|
| AEA3D | For 2-wire Transmitter (for single or dual redundant modules) |
8 pts x 4 | M4 screws | AAI135 AAI835 AAP135 |
KS1 | 1.8 kg | Insulation resistance: 100 MΩ or greater at 500 V DC Withstanding voltage: 500 V AC for 1 minute |
| AEA4D | For analog signals (for single or dual redundant modules) |
8 pts x 2 | M4 screws | AAI135 AAI835 AAP135 |
KS1 | 1.5 kg | |
| 16 pts x 2 | M4 screws | AAI141 AAV141 AAV142 AAV144 AAB841 AAI841 AAV542 AAV544 AAI143 AAI543 |
|||||
| AET4D | For thermocouple (for single or dual redundant modules) |
16 pts x 2 | M4 screws | AAT145 | KS1 | 1.8 kg | |
| AED5D | For digital signals (for single or dual redundant modules) |
32 pts x 1 | M4 screws | ADV151 ADV551 |
AKB331 | 1.5 kg | |
| ADV161 (*1) ADV561 (*1) |
AKB337 | ||||||
| AEF9D | For fieldbus (for single or dual redundant modules) |
4 ports x 4 | M4 screws | ALF111 | AKB336 | 1.8 kg | |
| AER4D | For resistance temperature detectors |
16 pts | M4 screws | AAR145 | AKB335 | 1.5 kg | |
| MRT(*2) | For resistance temperature detectors | 16 pts x 2 | M4 screws | AAR145 | KS8 | 1.8 kg | |
| AEC4D | For digital signals (for single or dual redundant modules) |
16 pts x 2 | M4 screws | ADV141 ADV142 ADR541 |
AKB332 AKB333 AKB334 |
1.8 kg | Insulation resistance: 100 MΩ or greater at 500 V DC Withstanding voltage: Between commons; 1500 V AC for 1 minute, common minus side every 8-channel Between signal and case; 2300 V AC for 1 minute |
| *1: |
Two sets of AED5D or AKB337 are required for one set of ADV161 or ADV561. |
