Yokogawa Terminal Board AEA4D-05

AEA3D

For 2-wire Transmitter
(for single or dual redundant
modules)

8 pts x 4

M4 screws

AAI135
AAI835
AAP135

KS1

1.8 kg

Insulation resistance: 100
MΩ or greater at 500 V DC
Withstanding voltage: 500
V AC for 1 minute

AEA4D

For analog signals
(for single or dual redundant
modules)

8 pts x 2

M4 screws

AAI135
AAI835
AAP135

KS1

1.5 kg

16 pts x 2

M4 screws

AAI141
AAV141
AAV142
AAV144
AAB841
AAI841
AAV542
AAV544
AAI143
AAI543

AET4D

For thermocouple
(for single or dual redundant
modules)

16 pts x 2

M4 screws

AAT145

KS1

1.8 kg

AED5D

For digital signals
(for single or dual redundant
modules)

32 pts x 1

M4 screws

ADV151
ADV551

AKB331

1.5 kg

ADV161 (*1)
ADV561 (*1)

AKB337

AEF9D

For fieldbus
(for single or dual redundant
modules)

4 ports x 4

M4 screws

ALF111

AKB336

1.8 kg

AER4D

For resistance temperature
detectors

16 pts

M4 screws

AAR145

AKB335

1.5 kg

MRT(*2)

For resistance temperature detectors

16 pts x 2

M4 screws

AAR145

KS8

1.8 kg

AEC4D

For digital signals
(for single or dual redundant
modules)

16 pts x 2

M4 screws

ADV141
ADV142
ADR541

AKB332
AKB333
AKB334

1.8 kg

Insulation resistance: 100
MΩ or greater at 500 V DC
Withstanding voltage:
Between commons;
1500 V AC for 1 minute,
common minus side
every 8-channel
Between signal and case;
2300 V AC for 1 minute

*1:

Two sets of AED5D or AKB337 are required for one set of ADV161 or ADV561.
