| Items | Specifications |
|---|---|
| Model | NFAV544 |
| Number of output channels | 16, Isolated |
| Output signal | -10 to +10 V |
| Withstanding voltage | Between input and system: 1500 V AC for 1 minute (*3) |
| Allowable load resistance | More than 5 kΩ |
| Accuracy | ±0.3% of full scale |
| Data refresh cycle | 10 ms |
| Output step response time | 40 ms |
| Output fallback (*2) | Set for each channel (*1) |
| Temperature drift | Max. ±0.01%/°C |
| Maximum current consumption | 860 mA (5 V DC) |
| Weight | 0.2 kg |
| External connection | Pressure clamp terminal, MIL connector cable (*3) |
