| Items | Specifications | |
|---|---|---|
| Model | AAT145 | AAR145 |
| Number of input channels | 16, isolated channels | 16, isolated channels |
| Input signal | TC: JIS C1602:1995 (*1), IEC584:1995 Type J, K, E, B (*2), R, S, T, N mV: -100 to 150 mV, -20 to 80 mV |
RTD: JIS C1604:1997 (*3), IEC751:1995 Pt100 (3-wire type) POT: Total resistance 100 Ω to 10 kΩ Span resistance: 50 % or more of total resistance |
| Switching input signals | TC/mV can be set individually for CH1 to CH16. | RTD/POT can be selected individually for CH1 to CH16. |
| Allowable input voltage | ±5 V | ±5 V |
| Withstanding voltage | Between input and system: 500 V AC (for single card: 1500 V AC), For 1 minute Between input channels: 200 V AC, For 1 minut |
|
