| Items | Specifications | |
| Model | AAP849 | |
| Number of I/O channels | 8-channel input /8-channel output, not-isolated | |
| I/O signal | Input: transistor contact (Open collector) | Output: 4 to 20 mA |
|---|---|---|
| Input frequency | 0 to 12 kHz | – |
| Pulse detection edge | Trailing edge | – |
| Allowable load resistance | – | 0 to 750 Ω |
| Circuit-open detection | – | Less than 0.65 mA |
| Accuracy | – | ±48 µA |
| Data update period | 1 ms | 10 ms |
| Output step response time | – | 40 ms |
| Temperature drift | – | ±16 µA/10 °C |
| Maximum current consumption | 310 mA (5 V DC), 250 mA (24 V DC) | – |
| Weight | 0.3 kg | |
| External connection | Dedicated cable (KS1) | |
