AAP135-S03 Yokogawa Analog I/O Modules (for FIO)
 Pulse Input Module (Isolated Channels)
This module receives contact ON/OFF, voltage pulse and current pulse. This is isolated between the field and the
system as well as between each channel.
It can be used in dual redundant configuration.
Manufacturer:
YOKOGAWA
Model:
AAP135-S03
  • yokogawa Analog I/O Modules AAP135-S03
  • yokogawa Analog I/O Modules AAP135-S03

Description

yokogawa Analog I/O Modules AAP135-S03

 Pulse Input Module (Isolated Channels)
This module receives contact ON/OFF, voltage pulse and current pulse. This is isolated between the field and the
system as well as between each channel.
It can be used in dual redundant configuration.
Items Specifications
Model AAP135
Number of input channels 8, isolated channels
Input signal (*3) 2-wire type: Contact ON/OFF, voltage pulse, current pulse
(possible to supply transmitter power supply)
3-wire type: Power-supply-type voltage pulse
Input frequency 0 to 10 kHz (*4)
Withstanding voltage Between input and system: 500 V AC, For 1 minute
Between channels: 500 V AC, For 1 minute (*1)
Minimum input pulse width 40 µs
Input signal level Contact input
Open/close levels of relay contact and transistor contact
Open: 100 kΩ or more, Close: 200 Ω or less
Contact capacity
When supplying 12 V DC: 15 V DC 15 mA or more
When supplying 24 V DC: 30 V DC 30 mA or more
Voltage/current pulse input (Current input is converted to voltage.)
VH (high level): 3 to 24 V DC
VL (low level): -1 to 8 V DC
VH-VL (swing value): 3 V or more
Signal source resistance: 1 kΩ or less
Shunt resistance Can be selected from none/200/500/1000 Ω.
(Open when power is OFF and for the standby side in a dual-redundant configuration)
Pull-up resistance 68 kΩ (12 V DC or 24 V DC)
Filter Filter for eliminating chattering can be set. (*2)
Data update period 2 ms
Transmitter power supply Can select 24 V DC/12 V DC.
Limiter value 12 V DC ±10 %: 40 mA, 24 V DC ±10 %: 30 mA
Maximum current consumption 300 mA (5 V DC), 400 mA (24 V DC)
Weight 0.3 kg
External connection Pressure clamp terminal, KS cable, MIL connector cable

*1: The withstanding voltage for using MIL connector cable depends on the electrical specifications of its cable.
*2: When the pulse input signal is dry contact (such as from a mechanical relay) up to 10 Hz, it is possible to eliminate the
chattering.
*3: The connection method of the field devices varies depending on the input signal.
For details, please refer to Installation Guidance (TI 33M01J10-40E).
*4: Input frequency is 0 to 800 Hz to receive no-voltage contact signals between terminal B and C.

Download
