Processor
VR5532 (350 MHz)
Main Memory Capacity
128 Mbyte
Communication Interface
Vnet/IP Interface: Dual-redundant
ESB Bus Interface: Dual-redundant or single (Always dual-redundant for AFV40D)
House Keeping (HK) Function
A House Keeping Unit (HKU) is standard hardware component provided with the type of FCU. With the HK function is able to monitor the environmental conditions of the connected cabinets via HK bus and/or optical ESB bus, and display HKU’s operating status on HIS.
System alarms can also be displayed.
Cable: HK Bus cable (AKBHKU)
Units that can be connected HKU of AFV40S, AFV40D: HKU of ACUKT1, ACUKT2, ACB51, or XLCabinet.
Maximum number of connectable cabinets: 9/FCU(AFV40S, AFV40D)
Total maximum length of cable: 100 m
Weight
Approx. 240kg (excluding node)
Approx. 360 kg (at max. node installation)
